Roof system automatic arched crimp curving machine

The arched roof panel usually used in metal roof building system, when rainning the arched roof panel can guiding the water from panel to floor.This kind of roof system can prevent hydrops effectively.

When useing this machine,each curve can change metal sheet for 10 degree, machine curve degree can be adjust.

The automatic arched crimp curving machine often match the metal sheet roof panel roll forming machine to use (If you buy the two kind of machines one time, maybe will get a superised discount !)

Roof system automatic arched crimp curving machine

Product Description

Roof system arched crimp curving roof panel material

  PPGI/GI/ aluminum/zinc


 Roof system automatic arched crimp curving machine


What's the dimension of the roof system arched crimp curving roof panel?

The regular coil input width

The output width will decied by the data in customer's profile drawing.


Packing list:

Series Quantity Remark
Feeding device  1
Rollers 3 stations 45# steel with chromed treatment
Cutting device  1
Hydraulic oil pump station 1 set
PLC control system 1set



Technical parameter

Roller station: 3 stations


Frame: 350 H steel

Transmission: Chains (gear also available)

Roller material:45# steel with chromed treatment

Roller shaft material:45# steel with quenched treatment

Work speed: 0-6m /min

Main motor power:0.85 KW

PLC brand: DELTA brand

Frequency brand:Mitsubishi brand

Work type:hydraulic type

Hydraulic motor power:5.5 KW

Weight: 1.8T


What's the different between our company and other manufactuters?

  • For the roller, the process is more than other manufacturers, include rough turning, heat treatment, finished turning and other process.
  • For the main roll former, we add some parts to make sure the machine can steady working.
  • PLC control box body is thicker than normal PLC box.
  • We provide over sea technical sopport if you needed.
  • We have brach office and showroom in India, you can invisit to Bombay office.And also have engineers resident oversea.
Contact person:
